Usb Rs485 Serial Converter Driver
- Connects to any serial RS485 device via USB Type A
- 9 Way D Male to USB A Male connectors
- Plug & Play - USB bus-powered with no external power supply required
- Compatible with Windows, Mac and Linux operating systems
- 2 year warranty
Right-click on the “USB Serial Converter” that displays with the yellow exclamation icon, and select “Update Driver Software” (Figure 14). Click on the “Browse my computer for driver software” button to continue (Figure 15). (FIGURE 15) Locate the driver in the CD provided and click on the “Next” button to continue (Figure 16).
The Lindy USB to Serial Converter allows the user to easily connect peripheral devices featuring 9 Way Serial RS485 to a USB Type A port. With both USB Type A and serial connectors, this device is a perfect solution for connecting legacy RS485 equipment such as barcode scanners and industrial devices to notebooks and Macbooks, in retail, IT and digital signage scenarios.
This converter is compatible with Windows, Mac and Linux operating systems. It supports hot-swapping so the user can quickly switch serial devices without shutting down the computer. The converter is USB bus-powered, it can be installed quickly and easily with no need for additional power supplies.
Browse By Category
- ATC Remote I/O Modules
- ATC PLC Controller
- Industrial Serial Device
Newsletter Signup
The ATC-820 is an Surge Protection USB to 1-Port RS-485 converter that is designed for PC, thin client, or server to provide instant COM port expansion via the Universal Serial Bus (USB). Supports Windows 95/98/Me, 2000, 2003, XP, Vista,Win7, CE, Linux.
The ATC-820 module is a cost-effective way to convert USB interface to RS-485 industrial buses. When connected to a PC USB port. The ATC-820 module is automatically detected and is installed as a native COM port which is compatible with any existing serial communication application.
The ATC-820 converter can be configured for RS485 two-wire (Half Duplex) networks. When operating in two-wire RS485 the data transfer control is automatically done by the converter./kingdom-hearts-2-pc-game.html.
The ATC-820 has a 384 byte receive buffer with an adjustable timeout and a 128 byte transmit buffer with auto-transmit control. The ATC-820 makes it easier to add RS-485 devices to your system with easy plug-and-play.
◆Using chip FTDI industry
◆Compatible with USB1.1, 2.0, the maximum rate can be up to 12 MBPS
◆Without setting location and IRQ, I/O and friendly user interface
◆Supports remote sensei and power management
◆A serial port transmission speed can reach 921.6 KBPS
◆Supports hot plug and PnP
◆Supports Windows 98 / ME / 2000 / XP / / 7/8 / CE/Vista, MAC and Linux 2.4.20
◆Interface electrostatic protection, signal lightning surge protection
| USB | |
| interface characteristic | Compatible USB1.0/1.1, 2.0, plug and play |
| interface form | The USB type A mouth |
| velocity | 12 Mbps (USB) at full speed |
| I/O address | BIOS appoint |
| IRQ | BIOS appoint |
| FIFO | 64 bytes |
| serial interface | |
| interface form | DB9 needle |
| Baud rate | 50 bps to 460.8Kbps |
| data bits | 5,6,7,8, |
| parity bit | None, Even, Odd, Space, Mark |
| flow control | XON/XOFF |
| Serial Signal | |
| RS-485 | 485+ ，485- |
| protection interface | |
| ESD protect | 15 kv esd protection, 1000 w lightning surge protection |
| Driver Support | |
| supported operating systems | Windows (2000, XP x86/x64, 2003 x86/x64,Vista x86/x64), WinCE 6.0, Linux 2.6 x86/x64 |
| Mechanical Characteristics | |
| body case | ABS + PC plastic shell |
| weight | 100 g (net weight) |
| size | 60 x 35 x 17 mm (USB cable length is 1000 mm) |
| Work Environment | |
| operating temperature | 0 to 55°C (32 to 131°F) |
| operating humidity | 5 to 95% RH |
| storage temperature | -20 to 70°C (-4 to 158°F) |
Company products are widely used with the electric power, industrial control, telecommunications, commerce, banking, insurance, security, smart CARDS, and other industries, production and sales of the products of the company, supporting complete, cost-effective, timely and thoughtful service.ATC - 820 is a USB transfer RS - 485 interface converter, 600 w surge protector, protect the equipment from lightning.Products are widely used in the attendance, entrance guard, selling rice, monitor, car park management, and other fields.Good product not only implement different signal transformation, communication, also let your computer extend the serial port resources.
| ATC-820 Products | 1PCS |
| ATC-820user's manual | 1PCS |
| ATC-820 CD | 1PCS |
